功率 power |
500W |
800W |
1000W |
1500W |
2000W |
3000W |
|
太陽能大充電電流 Maximum charging current of solar energy |
≤40A |
40A-60A |
||||
|
控制器類型 Controller type |
MPPT 控制器 controller |
|||||
|
太陽能板開路電壓 Open circuit voltage of solar panel |
≤80V |
≤120V |
||||
|
USB 大輸出電流 Maximum output current |
1000mA*2 |
|||||
|
直流 DC 座大輸出電流 Maximum output current of DC socket |
1A*4 |
|||||
|
電池電壓 Battery voltage |
DC12V |
DC24V |
||||
|
電池容量 Battery capacity |
＞100AH*1 |
＞200AH*2 |
||||
|
電池類型 Battery type |
鉛酸/膠體/鋰電池可選（電池需要客戶自備）Lead acid/colloid/lithium battery optional (the battery needs to be provided by the customer) |
|||||
|
蓄電池停充電壓 Battery stop charging voltage |
14V |
28V |
||||
|
蓄電池欠壓警告 Battery under voltage warning |
10V |
20V –21V |
||||
|
蓄 電池 過 壓 關斷 Battery over voltage shutdown |
15V |
30V - 32V |
||||
|
電 池 欠 壓 恢 復 Battery under voltage recovery |
14V |
25V - 27V |
||||
|
交流輸出頻率 AC output frequency |
50Hz±1% |
|||||
|
交流輸出波形 AC output waveform |
正弦波 sine wave |
|||||
|
交流輸出電壓 AC output voltage |
AC 220V±3% |
|||||
|
市電輸入電壓 Mains input voltage |
AC 220V±3% |
|||||
|
市電充電電流 Mains charging current |
10A-25A |
|||||
|
交流輸出功率 AC output power |
≤500W |
≤800W |
≤1000W |
≤1500W |
≤2000W |
≤3000W |
|
瞬間峰值功率 Instantaneous peak power |
1000W |
1600W |
2000W |
3000W |
4000W |
6000W |
|
工作環境溫度 Operating ambient temperature |
-10℃-45℃ |
|
-10℃-45℃ |
|||
|
包裝尺寸 Package size（CM） |
49*49*26 |
52*28*18 |
60*62*48 |
|||
|
重量 weight（KG） |
13 |
16 |
20 |
21 |
28 |
30 |
